NEW - Single Coil Shelf Cooler (12 Month Warranty) - BAR1H2A1
Regular price €495.00| Price: | Price Above is Vat Included - D12 Collection |
| Coils: | 1 product coil with NO2 Water Recirc flow/return pump piping. |
| Connections: | Coils and Pump ready for John Guest 3/8" push fittings. |
| Dimensions: | Height 255mm Width 360mm Depth 425mm |
| Availability: | Available |
The BAR100H* Eco Friendly Hydrocarbon R290 refrigeration system has been specifically developed and designed for improved energy efficiency.
The BAR100* develops 2.2Kgs of ice with impressive recovery times.
The unit can be factory configured for use with glycol based coolants for extra cold applications. Improved energy efficiency & performance – R290 vs R134a
Technical Specifications:
| Weight: |
Icebank weight: 2.2 kg nominal Packed: 18 kg Operational: 22 kg |
| Electrical: |
Mains supply: 230v 1ph 50Hz Run current: 1.1 amps Start current: 4 amps Fuse: 10 amps |
| Refrigeration: |
Compressor: 3 cc Compressor starting torque: Low starting torque Compressor duty (-10ºC Evap temp): 178 watts Water bath capacity: 5 litres Condenser type: Air cooled - Cu/Al construction Refrigerant type charge: R290 refer rating plate |
| Performance: |
Amount of product dispensed in the first hour with a ∆T of: 10ºC: 31 litres 20ºC: 16 litres |
| Controls: |
Ice Bank Control: Mechanical / Eliwell
|
| Fan Motor: |
Speed: 2750 rpm Protection: Impedance protected |
- I am responsible to ensure my gas and beer system is balanced correctly.
- I am responsible to ensure my gas and beer system is leak free.
- I am responsible for technical mistakes I may make with equipment.
- Keg dispense requires specialist equipment, reading, learning and listening.
- I agree to report any fault with this item within 2 working days of purchase.
- I agree to make every effort to return the item for inspection within 5 working days if there is a fault.
